Broward A&C 21099 Medical Gas Installation Kit NFPA

Broward A&C 21099 Medical Gas Installation Kit NFPA

Our Medical Gas Installation Kit is designed specifically for 6010‑certified medical gas plumbers working in hospitals, surgery centers, dental offices, and veterinary facilities.

What truly sets this kit apart is the integration of quick‑connect fittings at every low‑pressure connection point. Installers can transition seamlessly between gases without changing tools or fittings, significantly reducing installation time on multi‑gas systems.

The kit also includes specialized medical‑grade hoses engineered for dental gas installations—a feature not offered in any other installation kit on the market.

Comprehensive and code‑compliant, this kit provides everything required to begin installing medical gas piping immediately and in full accordance with NFPA 99 standards.

Included:

• 1 Medical Gas Kit Toolbox 22″ with Carry Handle
• 1 Nitrogen Pressure Regulator CGA 580 Adjustable to 0-400 PSI
• 1 Nitrogen Purge Regulator with Adjustable Flowmeter to 0-60 SCFH and Low N2 Alarm Gauge
• 1 Dual O2/N2O Purge Hose for Porter Dental Wall Outlets with Shut Off Valves and Quick Connect Adapters
• 1 Medical Grade Non-Conductive N2 Purge Hose 15 Ft with Quick Connect Adapters 250 PSI Max
• 1 Medical Grade Non-Conductive N2 Purge Hose 1 Ft with Quick Connect Adapters 250 PSI Max
• 1 In-line Particulate Filter Holder with Female Coupler
• 1 Safety Eyeglasses
• 1 De-Burring Tool
• 1 Pack of 6 Scotch-Brite Pads for Installing ASTM-B18 K or L Oxygen Cleaned Copper Piping
• 100 Particulate Filters 45-micron NFPA approved.
• 1 Maxtec O2 Analyzer with Lanyard and Adapters
• 1 Tee Purge Adapter with 400 PSI Gauge, Quick Connect Adapters, and Shut-Off Valve
• 5 Ohmeda Male Quick Connect Fittings (O2, N2O, AIR, VAC, WAGD)
• 5 Chemetron Male Quick Connect Fittings (O2, N2O, AIR, VAC, WAGD)
• 5 Puritan-Bennett Male Quick Connect Fittings (O2, N2O, AIR, VAC, WAGD)
• 6 DISS (Diameter Index Safety System) Hand-Tight Quick Connect Fittings (O2, N2O, AIR, VAC, WAGD, and N2)

All of these items can be bought individually, if one is lost or damaged you can contact us to purchase a replacement.  A full parts list is provided inside of each kit with part numbers and pricing.

All of these items can be bought individually, if one is lost or damaged you can always contact us to purchase a replacement.  Included in each kit is a full parts price list for your ordering convenience.
