Western FHM2-8-8 Innovator N2O Gas Manifold 8 Cylinders Standard
Western Innovator FHM2 Healthcare Gas Manifolds provide fully automatic system control. An integrated circuit board monitors cylinder bank pressure electronically, controlling changeover and eliminating the need to manually reset levers or valves. FHM2 Healthcare Manifolds meet NFPA99 2012 safety and performance requirements.
Easy-to-read digital displays show the line and individual bank pressures. A series of lights for each bank indicates whether the bank is in service, ready for use, or bank depleted.
NFPA Compliant, Fully Automatic Digital System
CSA Approved Power Supply included
Maximum inlet pressure: 3000 psig (2000 for CO2 and N2O systems)
Maximum Flow Rate: FHM2 2000 scfh (CO2 and N2O 35 scfh)
Internal Adjustable Dual Line Regulators: FHM2 30-70 psig
Manifold outlet: 1/2″ NPT Male
Relief Valve outlet: 1/2″ NPT Male
1/2″ Brass, silver brazed headers
Oxygen pigtails: NFPA 99 compliant, rigid copper with check valves
Other gas pigtails: NFPA 99 compliant, 24″ flexible stainless steel with check valves
Digital readout can display psig, kPa or Bar
Connects to remote alarm systems (Up to 3 amps 30 VDC or 2 amps 250 VAC)
